OEM-MC2 is Perfect for Thru-Transmission, research, and other demanding ultrasound applications. Low-frequency option also opens the door for applications like concrete inspection, guided wave, and other structural health monitoring research.
OEM-MC2 connects to a PC via Gigabit Ethernet and is powered with 12V. Its unique technology allows to acquisition of the A-scan with 27 bits of resolution, so analog gain is not required anymore (all the signal/dynamic from up to ±10V down to inside the noise floor is acquired and available for analysis in linear or logarithmic scale in the Software).
Each channel has a 400V pulser and a ±100V AWG (Arbitrary Waveform Generator) that permits to generation of tone bursts, Chirps, and Gaussian signals as well as any user-defined waveform. Full parallel 8 channels allow for fitting in any demanding application, such as thick forged parts as well as through transmission systems for bonding, composite, and honeycomb inspections.
Key Benefits:
- Unmatched Ultra-High performance
- Analog Gain No longer required (acquires the full dynamic range at once with a 27-bit A-scan resolution)
- Outstanding acquired dynamic range (156dB)
- Full-parallel 8ch
- 400V pulser as standard
- ±100V AWG (Arbitrary Waveform Generator) in standard too
